The PM300X2 is a solid choice if you're looking to drive a pair of coaxial speakers, component speakers, or a single subwoofer. The amplifier can also be run in stereo/mono mode simultaneously when using passive crossovers (not supplied) on all speakers. With proven PUNCH technology, the PM300X2 delivers real Rockford Fosgate power from a small design and is flexible to accommodate any moderately sized system.

Element Ready - Amps

These amplifiers are protected against Dust, UV, Corrosion, and feature Stainless hardware.

Our Moto-marine amplifiers have not only the capabilities you expect a Rockford Fosgate amp to have, but we have designed them to stand up to the environmental conditions you are likely to subject them to. With corrosion resistant stainless steel hardware and two-part epoxy coated circuit boards, these units are designed with you in mind. Whether on the lake, on the road or in the back woods these amplifiers are ready for an adventure.

Dust - We make sure that displays and motor structures are sealed up tight so they look as clear as possible and perform day in and day out no matter how many times you hit the trails.
UV Inhibitor Materials - Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in accordance with ASTM D4329 testing and certification procedures.
Corrosion Protection (Electronics) – Two part epoxy coated PCB boards prevent corrosion of critical components due to exposure in moisture rich environments.
Stainless Hardware – Stainless hardware is used due to its natural resistance to corrosion and rusting. This ensures that electrical connections will not degrade over time due to exposure to the elements.

CEA-2006 Compliant:     [CEA-2006 Guidelines] CEA-2006 Power Rating

• 100W x 2 @ 4Ω
• ≤1.0% THD+N

Number of Channels:     2

Rated Power
(RMS Continuous Power):

• 100 Watts x 2 @ 4-Ohm
• 150 Watts x 2 @ 2-Ohm
• 300 Watts x 1 @ 4-Ohm Bridged

Total Power (Sum of Rated Power):     300 Watts

Dynamic Power (PVC/PowerCube®):

• 120 Watts x 2 @ 4-Ohms 0° Res
• 203 Watts x 2 @ 2-Ohms 0° Res

• Bridgeable
• Frequency Response:     20Hz-20kHz
• Efficiency (average):     69% @ 4-Ohm

Total Harmonic Distortion (THD+Noise):

• 4-Ohm: <1.0%
• 2-Ohm: <1.0%

• Crossover Controls:     High-Pass: 50Hz - 250Hz @ 12dB/Octave Butterworth
• Low-Pass: 50Hz - 250Hz @ 12dB/Octave Butterworth
• All-Pass: Yes

Tone Controls:

• 0dB to +14dB @ 12.5kHz
• 0dB to +18dB @ 45Hz

• Input Sensitivity:     150 mV - 12 V
• Signal Input:     Hi/Low Level: 1 RCA Pair
• Signal Output:     Low Level: 1 RCA Pair
• Power Input Connector:     Captive C-Clamp
• Power Wire Gauge:     8 AWG to 4 AWG
• Speaker Output Connector:     Captive C-Clamp
• Speaker Wire Gauge:     8 AWG to 18 AWG
• Heat Sink Type:     Die Cast Aluminum
• Cooling:     Convection
• Remote Controls:     Optional Punch Level Control (PLC2) Ready

Visual Indicators:

• Power/Protect/Thermal LED
• Input Clip LED
• Output Clip LED

• Circuit Topology Class:     Class-A/B
• Operating Voltage:     9 - 16 VDC

• Recommended Fuse (not included):     50 A
• Max. Current Draw (13.8V Sinewave):     45 A
• Average Current Draw (13.8V Music):     23 A
• Suggested Alternator:     75 A

Shipping Weight:     9.5 Lbs. (4.3 Kg.)

Dimensions (H x W x D):     2.38 x 7.76 x 9.86 (in) 6.05 x 19.71 x 25.04 (cm)
