JVC CS-DR520
JVC CS-DR520
13cm (5-1/4") 2-Way Coaxial Speakers
- 2-Way Coaxial
- 260W Peak/40W RMS Power
- Frequency Response: 85 - 25,000Hz
- Sound Pressure Level: 88dB/W.m
- 13 cm (5-1/4") Carbon Mica Cone Woofer
- 2.5 cm (1") Poly-Ether Imide Balanced Tweeter
- Ferrite Magnet (Woofer/Tweeter)
- Neodymium Magnet (Tweeter)
- Hybrid Surround
- Mounting Depth: 44.5 mm (1-25/32")
Product Description
Specification
Woofer
- Size 13 cm (5-1/4")
- Diaphragm Carbon Mica Cone
- Surround Hybrid Surround (Rubber & Cloth)
- Magnet Ferrite
Tweeter
- Size 2.5 cm (1")
- Type Balanced
- Diaphragm Poly-Ether Imide
- Magnet Neodimium
General
- Frequency Response 85 - 25,000Hz
- Power Handling Capacity (RMS) 40W
- Power Handling Capacity (Peak Power) 260W
- Impedance 4 ohms
- Sound Pressure Level 88dB
- Weight
- Weight (w.Grille) 0.51kg (1.2lbs)
- Weight (w/o Grille) 0.46kg (1.1lbs)
- Magnet Mass 153g (5.4oz)
- Mounting Depth 44.5 mm (1-25/32")
