General

• Channels - Monoblock

• Physical dimensions (Height) - 54 mm (2.13")

• Physical dimensions (Width) - Monoblock (1500 W): 458 mm (18.05")

• Physical dimensions (Depth) - 177 mm (6.96")

Audio

• Amplifier class   Class D

• Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD) - Monoblock (1500 W): 750 W x 1

• Rated continuous (RMS) power (14.4 V input @ 2 Ohm < 1% THD) - Monoblock (1500 W): 1500 W x 1

• Rated continuous (RMS) power (12.5 V input @ 4 Ohm < 1% THD) - Monoblock (1500 W): 750 W x 1

• Rated continuous (RMS) power (12.5 V input @ 2 Ohm < 1% THD) - Monoblock (1500 W): 1200 W x 1

• Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs - Monoblock (1500 W): >82 dB

• Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs - Monoblock (1000 W / 1500 W): >50 dB

• Damping factor @ 4 Ω - Monoblock (1500 W): >1100/50 Hz

• Damping factor @ 2 Ω - >500/50 Hz

• THD+N @ Rated Power - <1% @ 2 Ω

• Frequency response (+0, -1dB) - 7 Hz-500 Hz

• Input voltage range @ RCA inputs - Switchable from 200 mV-2 V RMS (low) to 800 mV-8 V RMS (high)

• Fuse rating - Monoblock (1000 W): 80 A

• Recommended fuse type(s) - Monoblock (1500 W): AFS or AGU

• Min. copper power/Ground wire gauge - Monoblock (1500 W): 2 AWG wire

Signal Processing

• Filter mode(s): Channels 1 & 2 - Low-pass only

• Filter slope(s): Channels 1 & 2 - 12 dB/octave

• Filter frequency range: Channels 1 & 2 - 50 Hz-500 Hz

• Bass boost

• Bass boost EQ (0 to +12 dB @ 45 Hz)

• Remote level control - Optional (RBC-1)

• Pass-through preamp output - Buffered
