The APX 5 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter.The 5" cones surround features the exclusive shallow Triple Wave profile, for maximum excursion linearity.

Technical Specs LF

• Woofer Size - 130 mm (5 in)
• Impedance - 4 Ohm
• Power Handling - 150W Peak
• Power Handling - 50W Continuous
• Sensitivity - 93 dB
• Frequency Response - 70 ÷ 23k
• Voice Coil Diameter - 32 mm (0.59 in)
• Magnet Size - 85 x 40 x 13
• Xmax - 2 mm (1.26 in)

Technical Specs HF

• Tweeter Size - 24 mm (0.94 in)
• Voice Coil Diameter - 15 mm (0.59 in)

Electric-acoustic Specs

• Re - 3.1 Ohm
• Fs - 90 Hz
• Mms - 8.2 g (0.29 oz)
• Cms - 0.33
• Bl - 4.6
• Qms - 10.6Qes - 0,75
• Qts - 0.7
• Vas - 3.8 l (0.13 ft)
• LE - 0.07 mH

General

• Weight - 0.74 kg
