TECHNOLOGY OF GM SERIES
From dramatic distinction to dramatic design, Pioneer's new GM-Series amplifiers are thrillers in every sense, pushing the limits of flexibility and functionality.

VARIABLE LPF
Variable LPF (Low Pass Filter) allows for adjustable frequency between 40 Hz to 500 Hz* and greater car audio system flexibility according to subwoofer characteristics and personal listening preference.

BASS BOOST
Bass Boost featured in the GM-A6704 and GM-A5702 can be set to levels variably from 0 to 12 dB for optimal bass. This precise control can enhance the overall balance and impact of all sounds according to listening preference and music style. The GM-A5702 allows adjustment in three steps: 0 dB, 6 dB or 12 dB.

GROWING POWER, SHRINKING SIZE
New Pioneer amps brilliantly integrate high-power performance superior to that of previous models in space-efficient sizes for flexibility of installation in various car cabins.

AUTOMATIC SIGNAL SENSING AND TURN-ON
Pioneer amplifiers automatically select the proper input signal mode, either RCA or speaker level. When the receiver is turned on, the amplifier automatically turns on. When connected to an OEM receiver or a receiver without RCA output and utilizing speaker level output, the amp automatically senses the input mode and powers up in sync with the receiver.
When connected to an OEM receiver or a receiver without RCA output using speaker wire the amplifier is turned on at the same time as the receiver. Pioneer's amplifiers automatically detect the input signal and select RCA level or speaker level.

General

• Number of Channels     2
• Amplifer Class     Class AB
• Maximum Power Output     1000W
• Maximum Power Output at 2 Ohms     500W x 2
• Maximum Power Output at 4 Ohms     300W x 2
• Maximum Power Output - Bridged at 4 Ohms     1000W
• Nominal Power (RMS) Output at 2 Ohms     240W x 2
• Nominal Power (RMS) Output at 4 Ohms     150W x 2
• Nominal Power (RMS) Output - Bridged at 4 Ohms     480W x 1
• Frequency Response     10Hz ~ 70kHz (+0dB , -3dB)
• Total Harmonic Distortion (THD)     <0.05% ( 10W, 1kHz)
• Signal-to-Noise (SN) Ratio     > 96dB
• Fuse Rating     30Ax2

Specifications

• RCA Inputs     2-CH
• Speaker Level Inputs     Yes
• Crossover Type     Adjustable LPF
• Low-Pass Crossover Frequency     40-500 Hz
• Low Pass Slope (dB/octave)     -12db/oct
• Bass Boost Frequency     50Hz
• Bass Boost Level     0/6/12dB
• Automatic Signal Sensing and Turn-On     Yes
• Hi-Volt Input Level Control     0/6/12dB
• Terminal Type     Screw
• Load Impedance Allowance (Ohm)     2 to 4
• Bridgeable     Yes
• Protection Control System     Yes
• Dimensions (WxHxD)(inches)     356(W) X 60(H) X 215(D) mm
