Herein is the solution of the 4 Channel ZLOC4.4 Converter, a sophisticated audio converter designed to transcend these limitations, revolutionizing your in-car audio experience without necessitating a comprehensive system overhaul.

The 4 Channel ZLOC4.4 Converter emerges as a game-changing solution, bridging the gap between OEM systems and aftermarket audio components seamlessly. Its primary mission is to address the inherent constraints of factory-installed audio configurations. While vehicles nowadays boast built-in amplifiers, the original setup often falls short in delivering the desired sound.

The 4 Channel ZLOC4.4 Converter circumvents these limitations by bypassing OEM resistance whilst eradicating unwanted system noise, opening avenues for enhanced audio performance without compromising your vehicle’s factory settings.

Specifications

• Speaker Input: 4CH
• Outputs: 4CH
• REM In: Yes
• REM Out: Yes
• Load Select: 10-Ohm / 60-Ohm / 20K-Ohm
• Ground Isolation: GND/ISO/200-Ohm
• Gain: Yes X2
• Clipping: Yes X2
• Center Frequency: 20Hz-110Hz
• Bass Level: -9 ~ +9dB
• Turn On Mode: REM/DC/AUDIO
• Input Mode: 2CH/4CH
• Remote: None
• Dimensions: (LxWxH)mm 150.6x82x24.8mm
• Chassis Body: Aluminum
• Input Sensitivity: 0.5 to 32V
• Operating Voltage: 9 to 32V
• Output Voltage: Max. 7.5V @ 14.4V
• Max 40V as Input Must be 20K-ohm load
• Signal to Noise:  >100dB @6.4V output
• Input Impedance: 10-Ohm / 60-Ohm / 20K-Ohm
• Frequency Response: 10-30kHz
• THD+N: <0.01%
• Output Impedance: < 120-ohm
• Max Current Draw: 121 – 150 mA
• Turn-On Trigger: DC 3 to 7V
• Gain: -28 to 0dB
• Terminal Gauge: Quick Connect / 16 AWG
