Speaker Features

• Speaker System 2-way 2-speaker
• Speaker Type Coaxial
• Peak Input Power 160W
• Rated Input Power 40W
• Speaker Size 130mm
• Speaker Cone Design  Injection P.P.Cone
• Magnet Type Ferrit
• Terminals Slide type
• Installation Capability Door/Rear Deck

Speaker/woofer Specifications

• Peak Input Power 160W
• Maximum Input Power 70W
• RMS power (CEA spec) 40 W
• Woofer Cone material Injection P.P. Cone
• Speaker Basket Steel
• Speaker Surround Rubber
• Sensitivity 87dB/W/m
• Frequency Response 76Hz ~ 21000Hz
• Speaker Impedance 4Ω
• Dimensions with Grill (WxHxD) 160 x 160 x 81.5mm
• Dimensions w/o Grill (WxHxD) 132 x 132 x 74mm
• Mounting Depth 60mm
• Mounting Hole Diameter Ø 120mm
• Tweeter Height 14mm
• Speaker Weight with Grille (pc.) 797gr
• Speaker Weight w/o Grille (pc.) 726gr
• Gross Weight 1900gr
• Weight of Magnet 240gr

Tweeter Specifications

• Cone Size 25mm
• Cone Material Soft dome
• Magnet Type Neodymium

Accessories

• Screws (Parker-type) Ø 4 x 25mm, 8 pieces
• Speed nut φ 4, 8 pieces
• Adhesive Tape 50 mm
• Grille assembly included
• Grill holder 2 pieces
• Speaker cable 0.3m
