Key Features

• DAB+ Digital radio tuner built-in
• Bluetooth handsfree & audio streaming built-in
• Front USB 2.0 with 1,5A smartphone quick charge
• Made for iPod / iPhone
• MP3/WMA/AAC/WAV/FLAC playback
• KENWOOD Remote & Music Mix app ready
• DSP, DTA, 3-Way X'over & 13-band EQ built-in
• 3x RCA High Power Preouts (5,0V)
• Variable Colour Illumination (Key & Display)
• English/French/German/Russian & Spanish GUI language

General Features

• DIN Size 1 DIN
• Detachable Faceplate
• Key Illumination Variable LED
• Rotary Encoder & Control Knob
• Dual Accent Key Handsfree & Audio Streaming
• Back-up Memory Menu Settings
• Touch Sensor Tone
• Digital Clock (24H)
• Clock display when power-off default off
• All-off Select (20/40/60 minutes)
• Built-in Connector Mitsumi, 16 pin
• ISO connector, Mitsumi to ISO cable
• Bluetooth unit built-in
• Firmware upgreadable

Tuner Features

• Station Select Manual / Preset
• Tuner preset/recall key
• FM Reception
• AM (MW/LW) Reception
• Tuner Presets (FM/AM) 24 Presets (18FM / 6AM)
• Preset memory w/o back-up power
• Tuning mode Auto1/Auto2/Manual
• Up/Down Seek/Scan
• Automatic Memory Entry (AME)
• FM Stereo / Mono Selector
• Radio Data System
• Radio Text Plus
• Traffic Information
• Local search
• AF Regional Selectable: AF/AF Reg/OFF
• Auto TP search
• Enhanced Other Networks Function (EON)
• Program Type Function (PTY)

CD Features

• CD-R/RW Compatible
• MP3 Playback with ID3 Tag Display
• WMA (Windows Media Audio) Playback
• MP3, WMA & AAC playback
• AAC (Advanced Audio Coding) Playback
• CD Text Support
• D.A.C. processing 24bit
• 0 bit Mute
• Random Function DISC Random/Random OFF
• Repeat Function Track Repeat/All Repeat
• Fast Forward / Reverse play
• Tag Information Display

USB Features

• USB terminal, Front side with slide protection cover
• USB Type 2.0 Full speed
• Drive Change
• MP3 playback with ID3 Tag Display
• WMA (Windows Media File) playback
• AAC (Advanced Audio Codec) playback
• WAV (Waveform Audio Format) playback
• FLAC (Free Lossless Audio Codec) playback
• Repeat/Scan/Random search
• Repeat / Random Play
• Resume play
• Time code display
• 1,5A Smartphone Quick Charge

iPod Features

• Made for iPod & iPhone *
• USB Direct Control (Audio, 1 wire, Lightning-connector) with optional cable KCA-iP103
• Music playback
• Alphabet search
• Skip search
• Direct Search
• Control by hand
• Reverse browsin
• * Always update to latest Apple firmware

Audio Features

• Maximum Output Power 50W x 4
• MOSFET Power IC
• Auxiliary input, Front, Mini-jack
• Pre-out 3 RCA (FRONT/REAR/Subwoofer)
• Pre-out Output Level 5V
• Subwoofer Reference Level Adj.
• 2-Way X'over network
• 3-Way x'over (bi-amp connection)
• Balance/Fader/Loudness Control
• Loudness Control Off / LV1/ LV2
• Bass Boost Circuit Off/+1/+2/+3/+4/+5
• Equalizer built-in, 13 band with 8 presets
• Graphic Equalizer + Preset 13-Bands Graphic Equalizer with 8 Presets.
• Digital Sound Processor (DSP) Built-in
• Digital Time Aligment (DTA)
• Low- & High-pass Filter
• Speaker Size Control
• Kenwood Sound Reconstruction
• Sound Reconstruction
• Space Enhancer
• Realizer
• Stage EQ
• Drive EQ
• Extra EQ
• Sound Elevation

Connectivity

• iPod direct control, Built-in
• Front USB & AUX Input
• OEM Wired Remote Control ready, Optional interface needed
• DC-Cord NEW Mitsumi to ISO
• Power Control (P.CON) wire
• 2-way (Tel/Navi) mute wire
• Preout 3 x RCA (Front/rear/subwoofer)
• FM Antenna Input
• DAB Aerial input SMB connector
• External microphone input 3,5mm mini-jack

CD Specifications

• Laser Diode GaAIAs
• Digital Filter(D/A) 8 Times Over Sampling
• Digital/Analogue Converter 24 Bit
• Wow & Flutter Below Measurable Limit
• Frequency Response 20Hz ~ 20kHz (±1dB)
• Total Harmonic Distortion 0.01% (1kHz)
• Signal to Noise Ratio 96dB (1kHz)
• Dynamic Range 92dB
• Channel Separation 90dB
• MP3 Decoder Compliant with MPEG-1/2 Audio Layer
• WMA Decoder Compliant with Windows Media Audio
• AAC DecoderAAC-LC".aac" Files

USB Specifications

• USB Version compatibility USB 1.1 / 2.0 full speed
• File System FAT 32 / 16 / 12
• Maximum Supply current 1500mA
• MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
• WMA Decode Compliant with Windows Media Audio
• AAC Decode "m4a" & "aac" file encoded by AAC-LC format
• WAV Decode Linear - PCM Files
• flac Decode FLAC files up to 96kHz/24bit
• Frequency Response 20Hz - 20kHz
• S/N Ratio 99 dB (1kHz)
• Dynamic Range 93dB
• Channel Separation 90dB

Accessories

• Release keys 2 pieces
• Escutcheon
• Installation Sleeve
• DC cord (Mitsumi to ISO) 20 cm
• DAB antenna with 3 m cable
• Handsfree Microphone with 3 m cable
• Multi-Language Instruction Manual Included Quick-Guide
• Manuals Downloadable
