Key Features

• Bluetooth hands-free calls and music streaming
• DAB+ Digital radio, analogue FM radio with RDS functionality and AM radio reception
• Amazon Alexa cloud-based voice service ready
• Use your smartphone like a wireless remote control with the KENWOOD Remote app
• Enjoy audio streaming just by switching among 5 connected BT devices with Music Mix
• MP3 / WMA / AAC / WAV / FLAC music file playback
• Digital Sound Processor, Time Alignment & 13-Band EQ for optimal sound tuning enhancements
• 2 high power (2,5V) RCA preouts to connect multiple power amplifiers
• Wide 1,5-line LCD display with high contrast, wide viewing angle & variable-colour backlight

General Features

• DIN Size 1 DIN
• Detachable Faceplate
• Key Illumination Variable LED
• Rotary Encoder & Control Knob
• Dual Accent Key Handsfree & Voice Assistant
• Back-up Memory Tuner presets & menu settings
• Attenuator with Smooth Volume Return
• Touch Sensor Tone
• Digital Clock (24H)
• Clock display when power-off default off
• All-off Select (20/40/60 minutes)
• Built-in Connector Mitsumi, 16 pin
• ISO connector, Mitsumi to ISO cable
• Bluetooth unit built-in
• USB interface x 1 (Front)
• Firmware upgradeable

Display Features

• Display Type Liquid Crystal Display (LCD)
• Display Layout 2-line text + custom icons
• Vertical Alignment Liquid Crystal Display
• Display Illumination Variable by RGB LED
• Dimmer Control Manual / Set by Timer
• Brightness control 0 - 31 steps
• Demo Mode
• Menu text in selectable language English(default) / Spanish / French / German / Russian

Cosmetics Features

• Dress plate Piano Black
• Preset key finish Piano Black
• Escutcheon finish Piano Black
• Volume & operation knob or wheel Transparent Lighting & Chrome Finished Ring
• Triangle Illumination Red LED
• Front terminals dust cover
• Key illumination Variable by RGB LED
• Illuminated front USB port Variable by RGB LED
• Brightness Control (Key) 0 - 31 step
• Dimmer Control (Key) Manual / Set by Timer
• Variable colour illumination
• Colour Zone Concept 2 zone colour control
• Brightness zone concept 2 zone brightness control
• Chrome-finished accents Volume knob & faceplate

Tuner Features

• Station Select  Manual / Preset
• FM Reception
• FM Stereo / Mono Selector
• AM (MW/LW) Reception
• Up/Down Seek/Scan
• Tuner Presets (FM/AM) 24 Presets (18FM / 6AM)
• Mixed preset memory (FM & AM) 6 presets
• Automatic Memory Entry (AME)
• Tuner Preset Back-up Memory
• Radio Data System
• Radio Text Plus
• Traffic Information
• Local search
• AF Regional Selectable: AF/AF Reg/OFF
• Auto TP search
• Enhanced Other Networks Function (EON)
• Program Type Function (PTY)

CE DAB Tuner Features

• DAB+ tuner built-in
• Digital Radio Certification Mark
• Intelligent seek
• Ensemble seek
• Tuning mode / Seek mode Auto1/Auto2/Manual
• Service preset 6 ch * 3 bank presets,
• Auto service memory (AME)
• Service list by alphabet order
• Preset list
• Related service
• Audio interrupt standby by PTY
• Audio interrupt standby by announcement
• DAB-RDS integrated TI
• Traffic Information
• DAB-AF (Alternative frequency)
• Announcement Switching (ASW) Select
• DMB Audio (Digital multimedia broadcasting)
• Soft linking
• Antenna power supply on/off switch
• DAB antenna included
• Playable Audio File
• AAC (*.m4a) files are playable USB
• AAC (*.aac) files are playable CD/USB
• MP3 files are playable CD/USB
• WMA (.wma) files are playable CD/USB
• WAV (.wav) files are playable USB
• FLAC files are playable USB

CD Features

• CD-R/RW Compatible
• MP3, WMA & AAC playback
• CD Text with special Character Support English (default) / Spanish / French / German / Russian / Greek
• D.A.C. processing 24bit
• 0 bit Mute
• Random Function DISC Random/Random OFF
• Repeat Function Track Repeat/All Repeat

USB Features

• USB terminal, Front with dust cover
• USB Type 2.0 High speed
• MP3, WMA, AAC, WAV, FLAC playback
• Repeat/Scan/Random search
• Repeat / Random Play
• Direct search
• Last Position Memory / Resume
• Time code display
• 1,5A Smartphone Quick Charge

iPhone Features

• Made for iPod & iPhone *
• USB Direct Control (Audio, 1 wire, Lightning-connector) with optional cable KCA-iP103
• Music playback
• Alphabet search
• Skip search
• Related search
• Direct Search
• iPod EQ Mode
• Control by hand
• App & iPod control mode
• Spotify App Link
• iAP over Bluetooth
• iTunes Radio App iAP1
• Reverse browsing
• Battery charge + power control
• * Always update to latest Apple firmware

Audio Features

• Maximum Output Power 50W x 4
• MOSFET Power IC
• Auxiliary Type Mini-jack, front panel
• Pre-out 2 RCA
• Pre-out Output Level  2.5V
• Preout Rear / Subwoofer Switchable
• Subwoofer Reference Level Adj.
• 2-Way X'over network
• 3-Way x'over (bi-amp connection)
• Tone Control / Easy EQ 13 band, 8 presets
• Balance/Fader/Loudness Control
• Bass Boost Circuit Off/+1/+2/+3/+4/+5
• Att.(-20dB) with smooth Volume Return
• Easy 3-band EQ mode
• Graphic Equalizer + Preset 13-Bands Graphic Equalizer with 8 Presets.
• Digital Sound Processor (DSP) Built-in
• Digital Time Alignment (DTA)
• Low- & High-pass Filter
• Speaker Size Control, Front/rear/subwoofer independently
• Kenwood Sound Reconstruction
• Sound Reconstruction
• Space Enhancers
• Realizer
• Stage EQ
• Drive EQ

Bluetooth General Features

• Max num. of regist. phones for HFP & A2DP 5 phones
• Hands Free Profile with High Sound Quality  HFP V1.7.1
• Max num. of regist. phones for HFP 5 phones
• 2 phones full time connection
• Audio Streaming (A2DP)
• High Quality Audio Streaming SBC/AAC
• Max num. of regist. units for A2DP 5 units
• Serial Port Profile (SPP)
• Phonebook Access Profile (PBAP)
• iPhone & Android automatic pairing via USB
• KENWOOD Remote App Ready
• KENWOOD Music Mix Support
• Amazon Alexa ready
• Catchphone / Call Waiting
• Private mode
• Alphabet Search (Phonebook)
• Noise Canceller
• Echo Canceller
• Phone device status display
• Audio device status display
• Signal strength display
• Remaining battery display
• Bluetooth Paring Indicator
• High-quality noise cancelling microphone Rear Wired
• Bluetooth firmware upgradeable
• * depends on phone model/make & Kenwood unit

Connectivity

• Front USB & AUX Input
• DC-Cord Mitsumi to ISO
• Power Control (P.CON) wire
• Amplifier pre-out 2 x RCA: Front + Rear/Sub (selectable)
• FM Antenna Input JASO connector
• DAB Aerial input SMB connector
• External microphone input 3,5mm mini-jack
• OEM Wired Remote Control ready

Tuner Specifications

• FM range: 87.5Mhz - 108MHz (50Khz step)
• FM Usable Sensitivity  0.56μV/75ohm (S/N 30dBf)
• FM Quieting Sensitivity 1.58μV/75ohm (S/N 46dBf)
• FM Frequency Response 30Hz ~ 15kHz (± 3dB)
• FM Signal to noise ratio (Mono) 68dB
• FM Stereo Separation (1kHz) 40dB
• MW range: 531kHz - 1611kHz (9kHz step)
• MW Usable Sensitivity 28.5μV
• LW range: 153kHz - 279kHz (9kHz step)
• LW Usable Sensitivity  45μV

DAB Tuner Specifications

• Band III - Frequency range 174.928 MHz - 239.2MHz
• Sensitivity - 100dBm
• Signal to noise ratio 90dB
• DAB Aerial Connector Type SMB
• Output Voltage 14.4V (10.5V to 16V allowable)
• Maximum Current < 100 mA

Codec Specs

• MP3 Format MPEG 1/2 Audio Layer 3-Files
• WMA Format in accordance with Windows Media Audio
• AAC Format AAC-LC “.aac”(CD&USB) and ".m4a"(USB) files
• WAV Format RIFF waveform Audio Format (only for LinearPCM)
• FLAC Format FLAC files (up to 96kHz/24bit)

CD Specifications

• Laser Diode GaAIAs
• Digital Filter(D/A) 8 Times Over Sampling
• Digital/Analogue Converter 24 Bit
• Wow & Flutter Below Measurable Limit
• Frequency Response 20Hz ~ 20kHz (±1dB)
• Total Harmonic Distortion 0.01% (1kHz)
• Signal to Noise Ratio 97dB (1kHz)
• Dynamic Range 92dB
• Channel Separation 90dB
• MP3 Decoder  Compliant with MPEG-1/2 Audio Layer-3
• WMA Decoder Compliant with Windows Media Audio
• AAC Decoder   AAC-LC".aac" Files

USB Specifications

• USB Version compatibility USB 1.1 / 2.0 full speed
• File System FAT 32 / 16 / 12
• Maximum Supply current 1500mA
• D/A Converter 24bit
• MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
• WMA Decode Compliant with Windows Media Audio
• AAC Decode "m4a" & "aac" file encoded by AAC-LC format
• WAV Decode Linear - PCM Files
• flac Decode FLAC files up to 96kHz/24bit

Audio Specifications

• Maximum Power 50 W x 4
• Output Power (DIN45324,+B=14.4v)  22 W x 4
• Preout Level 2500 mV / 10 kOhm,
• Preout Impedance ≤ 600 Ohm
• Speaker Impedance 4 Ohm ~ 8 Ohm
• AUX Frequency Response 20 Hz ~ 20 kHz (±1dB)
• AUX Maximum Input Voltage 1000 mV
• AUX Input Impedance 30 kOhm

DSP Specifications

• Frequency band – Front 62.5Hz ~ 16kHz
• Equalizer Gain –9db ~ +9db
• Q Control 0.25/ 0.50/ 1.00/ 2.00
• High Pass Filter frequency Through/50 ~ 220 (Hz)
• High Pass Filter Slope  -12/-18/-24 dB/Oct
• Low Pass Filter frequency 50 ~ 120(Hz)/Through
• Low Pass Filter Slope -12/-18/-24 dB/Oct
• Time Alignment 0 — 610cm (2 cm step)
• Car type control
• ► OFF
• ► COMPACT
• ► Full SIZE CAR
• ► WAGON
• ► MINIVAN
• ► SUV
• ► MINIVAN LONG
• Equalizer Type Graphic
• Frequency band 13 bands

Bluetooth Specifications

• Technology Bluetooth V4.2
• Frequency 2.402 - 2.48 GHz
• Output power +4dBm(max), 0dBm (AVE) power class 2
• Maximum range Line of sight approx. 10 metres
• Handsfree profile (HFP)
• Serial port profile (SPP)
• Advanced audio distribution profile (A2DP)
• Audio Codec SBC/AAC
• Audio/Video remote control profile (AVRCP)
• Phonebook access profile (PBAP)

Accessories

• Release keys 2 pieces
• Escutcheon
• Installation Sleeve
• DC cord (Mitsumi to ISO) 15 cm
• DAB antenna with 3 m cable
• Handsfree Microphone with 3 m cable
• General Specifications
• Operating voltage 14.4V (10.5 ~ 16V Allowable)
• Maximum Current Consumption 10A
• Dark Current Consumption Below 1mA
• Dimensions (WxHxD) 182 x 53 x 155.5mm
• Weight 1200 gr.
• Operation Temperature Range -10°C ~ 60°C
• Instruction Manuals Multi-language quick Guide
