Specifications:

• DAB+ Digital radio, analogue FM radio with RDS functionality and AM radio.
• Front AUX input & Illuminated USB with dust cover
• MP3 / WMA / WAV / FLAC music file playback.
• USB High Current 1.0A Charging
• Wide 1 line LCD display with high contrast, wide viewing angle & white backlight
• Red key Illumination
• Digital Sound Processor
• Time Alignment
• 13-Band EQ for optimal sound tuning enhancements.
• 1 RCA Line Output (Rear/Subwoofer Selectable)
• Short body (100mm) for easy installation.
• Maximum Power Output (Front & Rear) 50W x 4

General:

• Rotary Encoder
• Beep Tone Support (From Speakers)
• Back Up Memory
• Wired Steering Remote Control Ready
• ISO Connector Cable
• Short Chassis
• Dimensions (W x H x D) 182 x 53 x 100mm
• Weight 0.60kg

Display:

• Detachable Face Panel
• Display Type 1-Line VA LCD Display
• LCD Colour White
• Key Color Red
• Music Sync. Effect
• Auto Dimmer
• Brightness Control
• Russian Text Compatible
• Spanish Text Compatible
• French Text Compatible

Radio Tuner DAB+ Tuner:

• DAB+ Frequency Band III 174928MHz to 239200MHz
• FM Tuner
• Radio Data System (RDS)
• FM Frequency Range 87.5 - 108.0MHz
• FM Usable Sensitivity 6.2dBf (0.56V/75 ohms)
• FM Quieting Sensitivity (46dB) 1.58uV / 75 ohms
• FM Stereo Separation 40dB
• LW Tuner
• LW Frequency Range 153 - 279kHz
• LW Sensitivity 45uV
• MW Tuner
• MW Frequency Range 531 - 1,611kHz
• MW Sensitivity 28,5uV
• Preset Stations 18FM + 6AM + 18DAB
• Tuner Preset Back-up Memory
• Automatic Preset / SSM (FM only)
• Digital Processing Tuner

Media Playback:

• Audio Decoder
• MP3 Compatible with Tag USB
• WMA Compatible with Tag USB
• WAV Compatible with Tag USB
• FLAC Compatible with Tag
• USB ( Up to 96kHz/24bit )

USB:

• Location Front
• Drive Change Mode for Mass Storage Class
• Random / Repeat Play
• 1.5A Max. Power Supply Current

Audio:

• Maximum Power Output (Front & Rear) 50W x 4 / 50W x 2 +Subwoofer (4 ohms) 50W x 1
• Full Bandwidth Power (at less than 1%THD) 22W x 4
• MOS-FET Amplifier
• Speaker Load Impedance 4 ohms (4 - 8 ohms allowable)
• K2 Technology
• EQUALIZER
• 13-Band Graphic EQ
• Preset EQ (8-preset)
• Easy EQ Setting
• Volume Link EQ
• High-Pass Filter/Low-Pass Filter
• Digital Sound Processor (DSP)
• Time Alignment
• Space Enhancement
• Sound Response
• Sound Lift
• Digital Track Expander
• Loudness Control (Off/Low/High)
• Bass Boost (Hyper Bass System)

Inputs and Outputs:

• Auxiliary (AUX) Input 1 (Front)
• Pre-Out Terminals 1 Pair (Rear/Subwoofer Selectable)
• Pre-Output Level 2.5V
• Pre-Out Impedance Less than 600 ohms
• Subwoofer Output with Level/Frequency Control (Level -8 - +8)
• Subwoofer Output Level 2.5V
