Enhance your audio system with the Hertz CENTO POWER CP 1.700, a mono amplifier that combines superior power handling and sophisticated sound control technologies. Boasting a superior power-to-size ratio with an efficiency of over 89%, this amplifier accommodates a broad voltage range, suitable for both conventional and electric vehicles.

General Specs

• Channels - 1
• Amp class - D

POWER SUPPLY

• Nominal power supply voltage (fuse) - 11 ÷ 15 VDC (2 x 25 A)
• Operating power supply voltage - 9 ÷ 18 VDC
• Idling current - 1.10 A
• Standby current draw - 4.5 uA
• Consumption, MIN load impedance (Max Musical Power) - 33 A
• Remote IN - 4 ÷ 17 VDC (1 mA)
• ART - Automatic Remote Turn on/off from SPK-IN (BTL radio only) - 1.5 VDC
• Efficiency - 89%

AMPLIFIER STAGE

• Distortion - THD @ 100 Hz, 70% Rated Power - 0,01 %
• Damping factor @ 1 kHz, 1W - 350
• Bandwidth @ -3 dB - 10 Hz ÷ 500 Hz
• S/N ratio (A-weighted @ 1 V Input) - 113 dBA

Minimum load impedance

• @ 1 Ch: 2 Ω
• Adjustable Crossovers - yes

Output Power

• Output power (RMS) @ 1% THD:
• 1Ch @ 4Ω - 400 W x 1
• 1Ch @ 2Ω - 700 W x 1
• Total Power - 700 W

INPUTS / FILTERS

• Inputs - Pre-In / Speaker-In
• Pre Out - Hi-Pass 50 ÷ 250Hz @ 12 dB/Oct.
• Pre-In sensitivity - 0.32 ÷ 8 VRMS
• Speaker-In sensitivity - 1.6 ÷ 40 VRMS
• Sub Ch Lo-Pass - OFF / 50 ÷ 250 Hz @ 24 dB/Oct.
• Bass Boost 50Hz - 0 ÷ 9 dB
• Subsonic Hi-Pass - OFF / 25 Hz @ 24 dB/Oct.
• Sub Remote Volume Control - -20 ÷ 6 dB (Active on Rear Ch with LPF ON)
• Remote Bass Controller - Optional HRC 02
