Much time was invested in the research of the perfect material for the C 165 woofer cones: through a long process of customisation of the materials SPP-M was selected (Semi Pressed Paper-Mica), which preserves the natural sound of the semi-pressed paper and enhances it with Mica powder improving rigidity. The result is an excellent balance between lightness and damping, essential for a powerful and controlled emission. The oversized ferrite magnet provides excellent control even at higher excursion.

Techincal Specs

• Component - Woofer
• Size mm (in.) - 165 (6.5)
• Power Handling - 70W Continuous
• Power Handling - 210W Peak
• Impedance Ohm - 4
• Voice Coil Ø - 25 (1)
• Frequency Response - 55Hz ÷ 7Khz
• Magnet size D x d x h mm (in.) - 85 x 32 x 15 (3.35 x 1.26 x 0.59)
• Weight of one speaker kg (lb.) - 0,96 (2.12)
• Magnet - High density flux ferrite
• Cone - Semi-pressed paper+ Mica
• Xmech mm (in.) - 4,9 (0.19)

Electro-acoustic Specs

• D mm - 131,5
• Re Ohm - 3,2
• Fs Hz - 60
• Le mH - 0,2
• Vas I-  13,24
• Mms g-  13,9
• Cms mm/N - 0,51
• BL T*m - 4,9
• Qts - 0,59
• Qes - 0,69
• Qms - 3,9
• Spl dB - 93

Accesories

• Optional Grill - CG165
