Special Order Only

Features

• 6.5” / 165 mm high-end midbass which combines outstanding sound performance with versatile physical integration options

• High efficiency and 3 Ohms technology for maximized power output of the amplifier

• Ultra High Damping (UHD) crafted paper cone for outstanding impulse response and unmatched frequency response

• High-tech polymer composite basket reinforced with glass beads for enormous rigidity and minimized ringing

• Specially shaped rubber surround for high linear cone excursion

• Polyurethane dustcap for optimized frequency response in the upper midrange area

• Large 1.46” / 37 mm voice coil ensures minimum thermal compression and high power handling

• Automotive grade ProConnect connection terminal allows the use of conventional speaker cables or a fast, secure and fail-safe connection via optionally available WireKits

• Powerful magnet system for highest efficiency and extremely low distortion

• Designed for the optionally available car-specific FlexMount165 adaptors which allow an acoustically optimized and professional integration in the original mounting location of the vehicle

• Designed for optionally available, car-specific WireKits which allow a non-destructive integration

• Made in Germany

Technical data

• Power handling - 150w RMS

• Power Handling - 225w Peak

• Impedance - Z - 3 Ω

• DC resistance - Re - 2.9 Ω

• Frequency response - 50 Hz - 3,500 Hz

• Resonance frequency - Fs - 60 Hz

• Mechanical Q factor - Qms - 3.00

• Electrical Q factor - Qes - 0.68

• Total Q factor - Qts - 0.55

• Compliance - Cms - 480 µm/N

• Equivalent air volume - Vas - 11.6 L

• Force factor - B*I - 4.8 Tm

• Sensitivity - SPL - 92 dB @ 2.83 V / 1m - 88 dB @ 1W / 1m

• Cone area - Sd - 131 cm²

• Moving mass - Mms - 14.8 g

• Cone material - Ultra high damping (UHD) crafted paper cone

• Mechanical resistance - Rms - 1.83 kg/s

• Voice coil diameter - ø - 37 mm

• Voice coil winding height - 13.4 mm

• Max. linear excursion - Xmax - +/- 3.7 mm

• Outer diameter ø - 165 mm / 6.5"

• Installation diameter - ø - 142 mm / 5.59"

• Installation depth - 65.8 mm / 2.59"

• Features - ProConnect terminal,

• FlexMount165

Compatibility

• FlexMount165

• WireKits

Scope of delivery

• 2 x Ci7 W165FM-S3

• 2 x Connection cable

• 2 x Mounting material
