Special Order Only

Features

• 8” / 200 mm performance woofer which combines outstanding sound quality with versatile physical integration options

• High efficiency and 3 Ohms  technology for maximized power output of the amplifier

• Unique Cenosphere coated paper cone for precise and detailed sound reproduction

• High-tech polymer composite basket reinforced with glass beads for enormous rigidity and minimized ringing

• Specially shaped rubber surround for high linear cone excursion

• Polyurethane dustcap for optimized frequency response in the upper midrange area

• 1” / 25 mm voice coil ensures high power handling

• Compact dimensions with maximum performance - despite the small outer diameter, this woofer comes with the same cone area known from typical 200 mm chassis

• Automotive grade ProConnect connection terminal allows the use of conventional speaker cables or a fast, secure and fail-safe connection via optionally available WireKits

• Powerful magnet system for high efficiency and optimum impulse response

• Universal mounting ring with grille included in delivery

• Designed for the optionally available car-specific FlexMount200 adaptors which allow an acoustically optimized and professional integration in the original mounting location of the vehicle

• Designed for optionally available, car-specific WireKits which allow a non-destructive integration

Technical data

• Power handling - 100w RMS

• Power Handling - 150w Peak

• Impedance - Z - 3 Ω

• DC resistance - Re - 3.0 Ω

• Frequency response - 50 Hz - 3,000 Hz

• Resonance frequency - Fs - 67 Hz

• Mechanical Q factor - Qms - 4.25

• Electrical Q factor - Qes - 0.93

• Total Q factor - Qts - 0.76

• Compliance - Cms - 300 µm/N

• Equivalent air volume - Vas - 19.0 L

• Force factor - B*I - 5.1 Tm

• Sensitivity - SPL - 94 dB @ 2.83 V / 1m - 90 dB @ 1W / 1m

• Cone area - Sd - 214 cm²

• Moving mass - Mms - 18.8 g

• Cone material - Paper with Cenosphere coating

• Mechanical resistance - Rms - 1.87 kg/s

• Voice coil diameter - ø - 25 mm

• Voice coil winding height - 11.6 mm

• Max. linear excursion - Xmax - +/- 3.8 mm

• Outer diameter - ø - 195 mm / 7.68"

• Outer diameter with universal mounting ring - ø - 208.9 mm / 8.22"

• Installation diameter - ø - 173.5 mm / 6.83"

• Installation depth - 63.7 mm / 2.51"

Compatibility

• Flexmount200

• WireKits

Scope of delivery

• 2 x Ci3 W200FM-S3

• 2 x Universal mounting ring with grille

• 2 x Mounting material
