Special Order Only

Features

• 2-way performance coaxial speaker system which combines outstanding sound quality with versatile physical integration options

• High efficiency and 3 Ohms technology for maximized power output of the amplifier

• Automotive grade ProConnect connection terminal allows the use of conventional speaker cables or a fast, secure and fail-safe connection via optionally available WireKits

Tweeter

• 0.75” / 20 mm performance tweeter with black aluminum dome for accurate, pure and detailed treble response

• High-quality aluminum dome with perfect balance of low weight and high rigidity – for natural brilliance and fine detail reproduction

• Refined highly efficient neodymium magnet for high magnetic flux linearity and optimized performance

Midbass

• 6.5" / 165 mm midbass with unique Cenosphere coated paper cone for precise and detailed sound reproduction

• High-tech polymer composite basket reinforced with glass beads for enormous rigidity and minimized ringing

• Powerful magnet system for high efficiency and optimum impulse response

Crossover

• Integrated with 6 dB slope

• Designed for the optionally available car-specific FlexMount165 adaptors which allow an acoustically optimized and professional integration in the original mounting location of the vehicle

• Designed for optionally available, car-specific WireKits which allow a non-destructive integration

Technical data

• Power handling - 100w RMS

• Power Handling - 150w Peak

• Frequency response - 60 Hz - 25,000 Hz

• Impedance - Z - 3 Ω

• Sensitivity-  SPL - 92 dB @ 2.83V / 1m - 88 dB @ 1W / 1m

• Outer diameter ø - 165.0 mm / 6.50”

• Installation diameter ø - 142.0 mm / 5.59”

• Installation depth - 60.7 mm / 2.39”

Midbass

• Impedance - Z - 3 Ω

• DC resistance - Re - 3.1 Ω

• Resonance frequency - Fs - 72 Hz

• Mechanical Q factor - Qms - 4.02

• Electrical Q factor - Qes - 1.04

• Total Q factor - Qts - 0.82

• Compliance - Cms - 466 μm/N

• Equivalent air volume - Vas - 11.5 L

• Force factor - B*l - 3.8 Tm

• Cone area - Sd - 133 cm2

• Moving mass - Mms - 10.4 g

• Mechanical resistance - Rms - 1.17 kg/s

• Voice coil diameter ø - 25 mm

• Voice coil winding height - 10.5 mm

• Max. linear excursion - Xmax - +/- 3.2 mm

• Tweeter - Voice coil diameter ø - 20 mm

Features

• Tweeter - Aluminum dome and neodymium magnet

• Midbass-  Paper with Cenosphere coating, ProConnect terminal and FlexMount165

• Crossover - Integrated, 6 dB highpass

Compatibility

• FlexMount165

• WireKits

Scope of delivery

• 2 x Ci3 C165.2FM-S3 MK2

• 1 x Mounting material
