Whether as a classic 4-channel system, a 3-channel configuration with subwoofer, or a bridged 2-channel layout: the 204 adapts flexibly to a wide range of vehicles and system requirements. With an output of 4 x 100 watts RMS at 4 Ω, 4 x 190 watts RMS at 2 Ω, or 2 x 380 watts RMS bridged at 4 Ω, it delivers more than enough power for ambitious setups.

Available as an X-OVER version with integrated active crossover or a DIRECT model optimized for pure signal transmission via external DSPs – always with a focus on superior sound performance.

Technical Data:

Power RMS  ≤ 1% THD+N @ 14.4 V

• @ 4 Ohms  4 x 100 Watts

• @ 2 Ohms  4 x 190 Watts

• bridged @ 4 Ohms 2 x 380 Watts

• Max. output power per channel* Up to 240 Watts RMS @ 2 Ohms

Technical Features:

• Amplifier technology Class D

• Inputs 4 x RCA / Cinch

• 1 x Remote In

• Input sensitivity  1 - 8 Volts

• Input impedance   67 kOhms

• Outputs 4 x Speaker output

• Output voltage RCA / Cinch

• Signal converter for digital input

• Frequency response  10 Hz - 20,000 Hz

• Signal-to-noise ratio (A-weighted)    99 dB @ full power

• Distortion (THD @ 1 kHz, 1 W into 4 Ohms) < 0.012%

• Distortion (THD+N @ 1 kHz, 1 W into 4 Ohms)  < 0.02 %

• Distortion (THD @ 100 Hz, 1 W into 4 Ohms)

• Distortion (THD+N @ 100 Hz, 1 W into 4 Ohms)

• Damping factor  70

• Operating voltage       10.5 - 16 Volts (max. 5 sec. down to 6 Volts)

• Idle current 1,100 mA

• Fuse 2 x 30 A LP-Mini-fuse (APS)

• Power rating   DC 12 V ⎓ 70 A max.

• Operating temperature range  -40 °C to +70 °C

• Additional features    Start-Stop capability, Clipping LED, DirectDSP inputs

• Dimensions (H x W x D)  40 x 248 x 114 mm / 1.58 x 9.76 x 4.49”

 * One channel driven (≤ 10 % THD+N @ 14.4 V)*
