MEDIAPLAYER

• AUX rear: Yes (Cinch/RCA)
• AUX detection/ source activation: No/ manual
• USB front: yes (type A, recessed jack)
• USB rear: No
• Memory card reader: No
• Concealed front inputs: Yes (USB)
• Compatible formatting (USB): FAT16, FAT32, exFAT
• Maximum storage size (USB, memory cards): > 128 GB
• Maximum file/folder count (USB, memory cards): > 20000
• CD- loader (für CDDA, CD-R, CD-RW): Yes
• Playback formats: MP2, MP3, WMA, FLAC, M4A/ AAC, WAV
• Display options (may depend on media file): ID3V2 (title, artist, album), folder, file, playing time
• Folder & file browsing: Yes
• Scrolling: Yes (one time / repetitive)
• iPod, iPhone control: Yes (via USB)
• Shuffle folder/ media: Yes/ Yes
• Repeat Title/ Folder/ All: Yes/ Yes/ Yes
• Introscan: Yes

BLUETOOTH

• Phone call: Yes
• Internal microphone: Yes
• Connectivity ext. microphone: Yes
• Answer/ reject call: Yes/ Yes
• Access phonebook: Yes (max. 1000 numbers)
• Audio streaming: Yes
• Audio streaming ID3 track display: Yes (Title, Artist, Album, Playtime)
• Scrolling: Yes (one time / repetitive)
• Voice assistant access
  (like Siri, Google, Alexa): Yes
• Cell phone navigation audio mix: No
• Auto wake-up on call: Yes (when radio off + ignition on)
• Fast pairing without PIN: Yes
• Automatic reconnection: Yes
• Bluetooth version: 5.0
• Number of paired devices: max. last 5
• No. of devices connected at the same time: Max. 1
• Supported profiles: A2DP, AVRCP, HFP, SPP
• Audio Codecs: AAC, SBC

*Availability/ support of functions depend on the phone/ app used!

SOUND

• Equalizer: Presets (Rock, Pop, Classical)
• Bass/ treble adjustment: Yes / yes (+/- 7 steps)
• Balance/ fader: Yes / yes (+/- 9 steps)
• HPF/ LPF: No
• Loudness: Yes
• Sound Presets: Rock, Pop, Classical
• Source specific sound adjustment: Yes
• Speaker Outputs (Channels): 4
• Preamp Outputs (Channels, Voltage): 4 (RCA, < 2V)
• Sub-Out (Channels, Voltage): 2 (RCA, < 2V, gain/ frequency variable)
• Max. Power: 4 x 50 watts
• Sine power at 14.4 V: 4 x 24 watts (according to DIN 45324)

GENERAL

• Display: LCD, negative, anti-reflective, wide angle, alphanumeric + symbols
• Illumination color display/ keys: Multi color, 7 colors (white, green, yellow, red, violet, blue, skyblue)
• Day/ Night mode: Yes (manual/ via dimmer connection)
• Brightness: Multi-level, variable (16 steps)
• Time display: Yes
• HMI languages: English, German
• Low standby current: Yes (< 3,5 mA )
• Antenna inputs: FM DIN/ ISO (with adaptor), DAB SMB (DAB with 12 V phantom power)
• Mute input/ Telephone mute: Yes (GND active)
• Ext. handsfree microphone connector: Yes
• Remote control: Yes (IR input for RC-10 and card remote)
• Steering wheel remote control (SWC): Yes (analog, programmable, pre-programmed)
• Variable scan time: Yes (4, 8, 12, 16, 60s)
• Confirmation beep: Yes (can be deactivated)
• Control panel type: Fixed panel
• Color panel/ decor ring: Black/ Black
• Software Update: via USB
• Permanent Memory: Yes (Settings & Presets)
• Demo Mode: Yes
• Weight: approx. 1.45 kg
• Dimensions: housing 52 x 178 x 170mm, front 188 x 58mm (H x W x D)
• Operating voltage: 10.5 – 14.4 V
• Power consumption: in operation: < 10A, 10 sec. after ACC power off: < 3.5 mA
