FEATURES

• High-current capability delivers high power into the most difficult loads (1Ω Stereo, 2Ω Bridged, for 5/6)
• Staggered power optimized for a 3-way active front with higher power for woofers, or 600W of bridged power for a sub 5 ch output operation mode to create a five-channel system, with 2Ω subwoofer
• Flexible crossover filter networks deliver Active 3-way, Front/Rear/Sub, or six channels of high-passed power
• ADT (Audison D-Class) Technology 2Ω stable output providing Hi-Res certified audio performance with superior efficiency in a compact size.
• Extruded aluminium compact design with a fan-less convection cooling system
• Built-in USS (Universal Speakers Simulator)
• Balanced high-noise rejection inputs for Speaker-In (for OEM head units) and RCA-In (for Aftermarket head units).
• ART (Automatic Remote Turn-On/Off) automatically turns on/off the amplifier when the OEM head-unit turns on/off (can be enabled/disabled, with Speaker-In inputs)
• Accepts up to 40-volt input signal (Speaker-In)
• Bass Boost (50 Hz) adjustable up to 12 dB, to increase the subwoofer punch
• Lo-Pass and Hi-Pass 12 dB adjustable (50 Hz to 5000 Hz) filters, providing the ability to build a 3-way system, a front 2-way + rear system, or a front 2-way + one powerful subwoofer (2Ω)
• Optional VCR-S2/ARC 01 Remote Volume Control provides the ability to adjust the OUT 5/6 volume level from the dashboard

AMPLIFIER TECH DATA

• Channels 6
• Class D-Class
• Efficiency >87%
• Hi-Level Input Yes
• Low Level Input Yes
• Digital Input No
• Power supply voltage / fuse 11 ÷ 17 VDC
• Operating power supply voltage 11 ÷ 17 VDC / 2 x 30A
• Idling current 2.2 A
• Idling current when off 0.04 mA
• Consumption @ 14.4 VDC, 2Ω, Max Musical Power  54 A
• Remote OUT 4 ÷ 15 VDC (150 mA)
• Remote IN 4 ÷ 15 VDC (1 mA)
• ART - Automatic Remote Turn on/off from OUTPUT BTL speakers (Selectable) 1.5 ÷ 7 VDC

AMPLIFIER STAGE

• Distortion - THD @ 100 Hz, 4Ω, 70% Rated Power 0.05 %
• Bandwidth A 10Hz ÷ 42 kHz
• S/N ratio A 102 dBA
• Damping factor A Ch/B Ch 100 / C Ch 400
• Input sensitivity Pre-In 0.32 ÷ 8 VRMS
• Pre In Impedance >10 kOhm
• Input sensitivity Speaker-In 1.6 ÷ 40 VRMS
• Input impedance Speaker-In 3Ohm ÷ 100kOhm (it depends by the Polyfuse specifications)
• Total Power RMS 1120 W
• Minimum load impedance Ch 1-4: 2Ω / Ch 5-6: 1Ω / 1+2/3+4 Bridged: 4Ω / 5+6 Bridged: 2Ω
• Output Power (RMS) @14.4 VDC, 1% THD

6Ch mode

• @4Ω: 85 x 4 + 110 x 2
• @2Ω: 140 x 4 + 185 x 2
• Ch1-4 @2Ω, Ch5-6 @1Ω: 140 x 4 + 300 x 2

5Ch mode

• @4Ω: 85 x 4 + 370 x 1 (Ch5/6 bridged)
• @2Ω: 130 x 4 + 600 x 1 (Ch5/6 bridged)

4Ch mode

• @4Ω: 280 x 2 (bridged) + 110 x 2
• @2Ω: 130 x 2 + 260 x 1 + 600 x 1

3Ch mode

• @4Ω: 280 x 2 + 370 x 1 (Ch5/6 bridged)
• 280 x 2 (Ch1-4 @4Ω) + 600 x 1 (Ch5/6 bridged @2Ω)
• Adjustable Crossover Yes

CEA SPECIFICATIONS

• Output power @ 4Ω, 1% THD+N, 14.4 V 75 W x 4 Ch + 85 W x 2 Ch
• SN ratio (ref. 1W output) A Ch, B Ch: 84 dBA, C Ch: 84 dBA

INPUTS

• Input Type Pre-In / Speaker-In
• Filter Pass A Full
• Hi-pass: 50 ÷ 500 Hz @ 12 dB/Oct.
• Filter Pass B Full
• Hi-pass: 50 ÷ 500 Hz @ 12 dB/Oct
• Band-pass: 50 ÷ 700 Hz (Hi) / 50 ÷ 5 kHz (Lo) @ 12 dB/Oct
• Filter Pass C Full
• Hi-pass: 50 ÷ 700 Hz @ 12 dB/Oct
• Lo-pass: 50 ÷ 700 Hz @ 12 dB/Oct
• Inputs/Outputs Sub CH -
• Inputs/Outputs Phase  No
• Inputs/Outputs Bass Boost No
• Inputs/Outputs Subsonic No
• Remote Sub Volume (-20 ÷ 6) dB

OTHER

• Weight 2.52 kg
