AUDISON APX4 - Prima 4" Coaxial Speakers
AUDISON APX4 - Prima 4" Coaxial Speakers
The APX 4 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter. The 4" cones surround features the exclusive shallow Triple Wave profile, for maximum excursion linearity.
Product Description
The APX 4 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter. The 4" cones surround features the exclusive shallow Triple Wave profile, for maximum excursion linearity.
Technical Specs LF
- Woofer Size - 100 mm
- Impedance - 4 Ohm
- Power Handling - 120W Peak
- Power Handling - 40W Continuous
- Sensitivity - 91 dB
- Frequency Response - 80 ÷ 23k
- Voice Coil Diameter - 32 mm (0.59 in)
- Magnet Size - 75 x 40 x 10
- Xmax - 1.3 mm (1.26 in)
Technical Specs HF
- Tweeter Size - 24 mm (0.94 in)
- Voice Coil Diameter - 15 mm (0.59 in)
Electric-acoustic Specs
- Re - 3.1 Ohm
- Fs - 125 Hz
- Mms - 5.3 g (0.19 oz)
- Cms - 0.3
- Bl - 3.2
- Qms - 8
- Qes - 1,2
- Qts - 1
- Vas - 1.5 l (0.05 ft)
- LE - 0.04 mH
General
- Weight - 0.49 kg
