AUDISON AP8 - Prima 8" Mid Woofers
AUDISON AP8 - Prima 8" Mid Woofers
For the vehicles equipped with an 8 inch woofer as standard OEM component, the Audison Technical Department developed the AP 8 which, also thanks to the wide emission surface, provides higher energy in the low frequency range, ensuring excellent performance when the use of a subwoofer is prohibited due to space limitations.
Product Description
For the vehicles equipped with an 8 inch woofer as standard OEM component, the Audison Technical Department developed the AP 8 which, also thanks to the wide emission surface, provides higher energy in the low frequency range, ensuring excellent performance when the use of a subwoofer is prohibited due to space limitations.
Technical Specs
- Nominal diameter - 200 mm (8 in)
- Impedance - 4 Ohm
- Power Handling - 300W Peak
- Power Handling - 100W Continuous
- Sensitivity - 93.5 dB
- Frequency Response - 35 ÷ 3k Hz
- Voice Coil Ø - 25 mm
- Magnet Material - HIGH DENSITY FLUX FERRITE
- Magnet size D x d x h - 90 x 40 x 17 mm (in.)
- Xmax - 3.3 mm (0.13 in)
Electric-acoustic Specs
- Re - 3.1 Ohm
- Fs - 60 Hz
- Le - 0.3 mH
- Vas - 20 l (0.706 ft)
- Mms - 19 g (0.67 oz)
- Cms - 0.35 mm/N
- BL - 5.4 T•m
- Qts - 0.7
- Qes - 0,8
- Qms - 5
General
- Weight - 1.2 kg
