Elevate your audio experience with AudioControl’s Altitude Amplifier Series, designed from the ground up to be sleek and modern with a minimalist aesthetic. The anodized matte grey aluminum chassis provides superior thermal dissipation. Performing at the top of their class, these amplifiers offer robust power and exceptional quality.

FEATURES

• High/Low Input Modes
• GTO™ Signal Sense
• Linkwitz-Riley Crossovers
• Start-Stop Compliant
• High Power Output in a Sleek Chassis
• ParaBASS® Low Frequency Contouring
• Valet Mode Option
• Optional Remote Level Control (ACR-1)
• EV Compliant up to 17V
• Spike Mode Enabled

SPECIFICATIONS

INPUTS

• Preamp Inputs: 2
• Line-Level Inputs: 6 V max
• Speaker-Level Inputs: 20 V max

OUTPUTS

• Rated Continuous (RMS) Power at 14.4V
• 400W x 1 @ 4Ω
• 600W X 1 @ 2Ω
• 800W x 1 @ 1.33Ω
• Remote Level Control - ACR-1 (optional)

WEIGHTS & DIMENSIONS

• DIMENSIONS: 10.9” W x 6.7” D x 2.1” H
• WEIGHT: 6.05 lbs

PERFORMANCE

• S/N Ratio (ref: rated power): 110.2 dBA
• THD+N: <0.14%
• Power / Ground Wire Gauge: 4 AWG
• Recommended Fuse rating: 100A
• Valet Mode: Yes
• Subsonic Filter: Variable
• Linkwitz-Riley X-Over:
• Low Pass
• Freq. Range: 60 Hz to 120 Hz
• Bass Processing: ParaBASS®

WHAT'S IN THE BOX

• A800.1
• Manual
